Description
-
Comes with concealed Cistern
-
with flushing cistern 6 - 3 l
-
for on-the-wall installations or studded walls
-
including WRAS approved filling valve
-
powder coated steel frame, self-supporting
-
TÜV approved
-
2 WC fixing bolts
-
fixing device for ceramic
-
WC ceramics with small bearing area (< 205 mm) require additional accessory 38 779 000
-
distance of fixing bolts 180/230 mm
-
outlet bend Ø 90 mm
-
depth adjustable
-
reducer Ø 90/110 mm
-
inlet and outlet connecting set
-
flushing cistern 6 - 9 l containing the following features:
-
water supply from left/right or back
-
Insulated against condensation
-
½" water supply connection including integrated angle valve and push fit flexible hose union
-
for on-the-wall installation please order wall brackets 38 558 00M (sold separately)
-
for mounting of small flush plates please order revision shaft 40 950 000 (sold separately)
-
Product Type: Wall Hung Toilet Frame
-
Height: 985mm
-
Width: 500mm
-
Depth: 145mm-165mm
-
Finish: White/Blue
-
Shape: Rectangular
-
Mounting: Wall
-
Style: Modern
